28" Spiral Welded blade stabilizer, 11" OD body with 8-5/8" Reg. box down and 8-5/8" H90 box up.

Product Categories
Hebei E-valves Petroleum Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

28" Spiral Welded blade stabilizer, 11" OD body with 8-5/8" Reg. box down and 8-5/8" H90 box up.

Brand Name : China Brand

Model Number : 28" String/Near Bit Stabilizer

Certification : API 7-1

Place of Origin : China

Payment Terms : T/T

Delivery Time : 20-40 days

Packaging Details : Wooden case

Material : 4145H

Model : Welded Blades

Hard Facing : HF1000-HF5000

Connection : NC 50

Contact Now

28" Spiral Welded blade near bit/string stabilizer, 11" OD body with 8-5/8" Reg. box down and 8-5/8" H90 box up.

Product Specifications
Attribute Value
Material 4145H
Model Welded Blades
Hard Facing HF1000-HF5000
Connection NC 50
Product Description

28" Near Bit/String Spiral Welded/String Blade Stabilizer featuring an 11" fishing neck with 8 5/8" Reg. box connection and 8-5/8 H90 box up configuration.

Detailed Specifications
Attribute Value
Stabilizer Type Near Bit/String Spiral Welded Blade
OD 28 inches
Fishing Neck 11 inches
Connection 8 5/8" Reg. box x 8-5/8 H90 box up
APPLICATION
We supplies a complete line of downhole drilling stabilizers to increase rate of penetration and control hole deviation problems. All these stabilizers (including spiral blade, straight blade, integral blade, welded blade, sleeve-type, and stainless steel nonmagnetic types) are designed to meet or exceed the strictest quality control and quality assurance standards. All alloy stabilizers are manufactured from AISI 4145H modified heat-treated steel for a wide variety of configurations and hole sizes

FIVE KINDS OF HARD FACING
1. HF1000: Crushed tungsten carbide inserts(TCI) held in a nickel bronze matrix
2. HF2000: Trapezoidal tungsten carbide inserts(TCI) held a sintered carbide nickel bronze matrix
3. HF3000: Embedded with trapezoidal tungsten carbide inserts (TCI) spray welded on the blades
4. HF4000: Tungsten carbide inserts (button type)are pressed tightly in the holes of blades at room temperature
5. HF5000: This oxy-acetylene process pplies tough molten carbide particles of varying sizes in a nickel chrome matrix

TECHNICAL DATASHEET
28" Spiral Welded blade stabilizer, 11" OD body with 8-5/8" Reg. box down and 8-5/8" H90 box up.
